China Trailer Mounted Mud Pump Unit Manufacturer, Factories

â€¢ Mobility: The trailer-mounted mud pump unit enables rapid relocation across well sites, reducing rig-up time and logistics cost.
â€¢ Space Efficiency: Designed with compact layouts to fit transportation and site access limitations without compromising output.
â€¢ Integrated Systems: Each pump unit can be configured with power packs, manifolds, charge pumps, fuel tanks, and control panels,all on a single chassis.
â€¢ Versatility: Compatible with a wide range of drilling fluid systems and adjustable for different flow and pressure requirements.

Send Inquiry

Product Description

📋 Product Specifications

Product model	TMPUF500 / TMPUF800 / TMPUF1000
Application	Suitable for land drilling operations requiring mobile, high-pressure mud circulation systems.
Pump Working pressures	5000 PSI (35MPa)
Power System	Range of diesel engines available, including models from CNPC Jichai, Caterpillar, or Cummins. Engine output is matched to pump requirements to ensure steady and efficient performance.
Transmission Assembly	Supports both domestic and imported hydraulic torque converters, paired with either belt and pulley mechanisms or custom transmission interfaces for optimized service life.
Mud Pump Options	Available with F500, F800, or F1000 triplex mud pumps conforming to API 7K specifications for durability and standardization.
Mounting Platform	Heavy-duty trailer frame designed for road transport. Integrated fuel tanks, manifolds, pulsation dampeners, and control panels based on layout requirements.
Third Party Inspection	Witness and inspection reports available from Bureau Veritas (BV), CCS, ABS, SJS, etc.

🚀 Product Features

✔

Engineered for rugged field conditions with flexible configuration options to meet various drilling requirements.

✔

Modular approach allows for tailored design while maintaining a high standard of manufacturing consistency.

✔

Ideal for land-based drilling operations where mobility, reliability, and quick setup are essential.

✔

All components conform to industry standards, ensuring ease of service and part identification in field operations.

🖼️ Product Details

❓ Frequently Asked Questions

Q1: What are the main models available for the trailer-mounted mud pump units? The units are available in three primary models: TMPUF500, TMPUF800, and TMPUF1000, tailored to different flow and pressure requirements.

Q2: Which engine brands can be used with these pump systems? Customers can select from several industry-leading diesel engine brands, including CNPC Jichai, Caterpillar, or Cummins, to ensure regional support and operational efficiency.

Q3: Do these mud pump units comply with international standards? Yes, all triplex mud pumps used in these units conform to API 7K specifications, ensuring high durability and part standardization.

Q4: What is the maximum working pressure for these units? The system is designed to handle working pressures up to 5000 PSI (35 MPa), suitable for high-pressure land drilling applications.

Q5: Can the layout be customized for specific field requirements? Yes, the fuel tanks, manifolds, pulsation dampeners, and control panels are integrated into the heavy-duty trailer frame according to client-specific layout and space requirements.

Q6: Are third-party inspections supported? Absolutely. Inspection reports from recognized bodies such as Bureau Veritas (BV), CCS, ABS, and SJS are available upon request.
